CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment

  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
  • CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment
Luogo di origine Guangdong, Cina
Marca MYSUN
Numero di modello CQC20011252316
Quantità di ordine minimo 3050

Contattimi gratis campioni e buoni.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se avete di preoccupazione, forniamo la guida in linea di 24 ore.

x
Dettagli
Materiale conduttore Rame in scatola Diametro 0,051 mm2, 0,08 mm2, 0,13 mm2, 0,21 mm2, 0,32 mm2, 0,40 mm2, 0,52 mm2, 0,75 mm2, 0,82 mm2, 1,00 mm2,
Materiale isolante FEP Tensione nominale 600v
Tipo di conduttore Solido Forma Girare
Valutazione della temperatura 150°C, 200°C, 200°C Tipo Isolato
Lunghezza dell'unità 305/1000 Resistenza al conduttore massima 381, 239, 150, 94.2, 59.4, 46.6, 37.4, 24.8, 23.5, 18.7, 14.7, 12.5, 9.22, 7.47, 5.75, 4.68, 3.62, 3
Spessore nominale 0.510mm Diametro isolamento 1,32 mm, 1,40 mm, 1,50 mm, 1,62 mm, 1,80 mm, 1,90 mm, 2,00 mm, 2,15 mm, 2,20 mm, 2,40 mm, 2,60 mm, 2
Diametro del conduttore 0,30 mm, 0,38 mm, 0,48 mm, 0,60 mm, 0,78 mm, 0,85 mm, 0,96 mm, 1,12 mm, 1,17 mm, 1,35 mm, 1,52 mm, 1 Costruzione 7/0.10, 7/0.127, 7/0.16, 19/0.12, 19/0.15, 19/0.17, 19/0.19, 19/0.225, 19/0.235, 19/0.26, 19/0.30, 1
Dimensione awg 0.051, 0.08, 0.13, 0.21, 0.32, 0.40, 0.52, 0.75, 0.82, 1.00, 1.31, 1.50, 2.08, 2.50, 3.31, 4.00, 5.2
Evidenziare

GB/T38296-2019 Standard FEP Wire

,

UAV Motor Generator FEP Wire

,

Medical Equipment FEP Wire
Lasciate un messaggio
Descrizione di prodotto
CQC FEP Wire 600V 200°C Tinned Nickel Plated Copper High Temperature E-200/TX/FEP Wire for UAV Motor Generator
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 0 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 0
Specification
CQC V048486 CQC20011252316 E-200/TX/FEP UL1330 Conductor Insulation Max. Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size (AWG) Construction (No.mm) Diameter (mm) Nominal thickness (mm) Diameter (mm)
0.051 7/0.10 0.30 0.510 1.32 381 610/2000
Click Contact us Get the Best Quote
Company Profile
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 2 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 2 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 4 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 4
Our Products
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 6 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 6
Application
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 8 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 8
Our Overseas Clients
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 10 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 10
Exhibition
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 12 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 12
Certifications
CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 14 CQC Certified FEP Wire with GB/T38296-2019 Standard for UAV Motor Generator and Medical Equipment 14
FAQ
1. Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
2. What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
3. Why Choose Us?
  • Free Sample
  • Competitive Price
  • High Quality Standard
  • Customized Service
4. What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
5. What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
