UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications

  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
  • UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications
Luogo di origine Guangdong, Cina
Marca MYSUN
Certificazione UL/CCC/CE/VDE/SA ETC.
Numero di modello UL3512
Quantità di ordine minimo 6100
Dettagli
Materiale conduttore Rame Diametro 2 AWG, 1 AWG, 4 AWG, 6 AWG, 8 AWG, 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 25 mm2, 35 mm2, 5
Materiale isolante Silicone Tensione nominale 600 V, 1000 V, 1500 V
Tipo di conduttore Incagliato Forma Girare
Intervallo di temperatura -80°C ~ +200°C Spessore dell'isolamento 0,78 mm, 1,15 mm, 1,52 mm, 2,03 mm
Costruzione del conduttore Rame stagnato/Personalizza Spessore nominale 0,78 mm, 1,15 mm, 1,52 mm, 2,03 mm
Schermatura Opzionale Diametro del filo 0,48 mm - 16,3 mm
Conta dei fili 25-13422 Diametro del filo 0,08 mm
Diametro isolamento 2,10 mm - 16,3 mm
Evidenziare

UL Standard Battery Connection Cable

,

High Temperature Silicone Wire

,

High Voltage New Energy Cable
Lasciate un messaggio
Descrizione di prodotto
UL3512 Super Soft Silicone Wire Specifications
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 0 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 1
Conductor Insulation
Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm)
2625/0.080.480.782.10±0.1
2441/0.080.600.782.20±0.1
2265/0.080.780.782.50±0.1
20104/0.080.950.782.55±0.1
18164/0.081.170.782.80±0.1
16261/0.081.470.783.10±0.1
14415/0.082.100.783.70±0.1
12660/0.082.700.784.30±0.1
101050/0.083.40±0.301.155.50±0.2
91320/0.083.80±0.31.156.10±0.3
81650/0.084.00±0.301.156.30±0.3
72100/0.084.80±0.31.527.90±0.3
62648/0.085.30±0.301.528.30±0.4
53338/0.086.10±0.51.529.20±0.4
44210/0.086.80±0.51.529.90±0.4
35309/0.087.80±0.51.5210.9±0.5
26692/0.088.70±0.51.5211.8±0.5
18842/0.0810.0±0.62.0314.0±0.6
1/010647/0.0811.0±0.702.0315.0±0.6
2/013422/0.0812.3±0.82.0316.3±0.7
Contact Us to Get the Most Cost-effective Quote
Our Products
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 2 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 3
Application
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 4 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 5
Company Profile
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 6 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 7 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 8 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 9
Our Overseas Clients
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 10 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 11
Exhibition
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 12 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 13
Certifications
UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 14 UL Standard Battery Connection Cable High Temperature High Voltage Silicone Wire for New Energy Applications 15
Frequently Asked Questions
1. Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
2. What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
3. Why Choose Us?
A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
4. What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
5. What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
